Accuracy : ± 2 % of reading plus 0.01 NTU from 0 to 1000 NTU / ±5% of reading from 1000 to 4000 NTU
Air Purge : 0.1 scfm at 69 kPa, hose barb connection for 1/8 in tubing, maximum138 kPa. Dry nitrogen or instrument-grade air.
Compliance Certifications : UL/CSA
Dimensions (H x W x D) : 156 mm x 400 mm x 305 mm
Display Type : 8-digit LED display
Interface : RS232 serial (bi-directional)
Manual Languages : English, Spanish, French
Max. operating humidity : 90 %
Measurement Modes : NTU, EBC, Nephelo
Measurement Range 2 : 0 to 9.99 NTU NTU mode, ratio on: manual
Measurement Range 3 : 0 to 99.9 NTU NTU mode, ratio on: manual
Measuring range : 0 to 4000 NTU NTU mode, ratio on: auto, auto decimal / 0 to 4000 NTU NTU
Operating Temperature Range : 0 to 40 °C
Power Requirements : 115 - 230 VAC; 50 to 60 Hz; 60 VA maximum
Range : 0 to 4000 FNU
Ratio On : Manual 0 - 10000 ; Auto 0 - 10,000 auto decimal; Ratio Off: 0 - 40.0
Range 2 : with ratio on
Regulatory : USEPA method 180.1
Repeatability : ± 1 % of reading or ± 0.01 NTU, whichever is greater
Resolution : 0.001 on lowest range
Response Time : 6.8 s with signal averaging off; 14 s with signal averaging on
Sample Cell Compatibility : 25mm round; 12, 13, 16, and 19 mm round with optional adapter kit
Sample Volume : 30 mL with 25 mm sample cells
Source Lamp : Tungsten lamp
Stabilization time : 30 min with ratio on / 60 min with ratio off
Storage Conditions : -40 °C to 60 °C
User Interface : Button
User Interface Languages : English
Weight : 8.31 lbs. (3.77 kg)
Instrument, sample cells, Stablcal calibration standards in sealed vials, silicone oil, oiling cloth, dust cover, manual, power cord with Continental European plug, EPA filter assembly.
