Accuracy

FNU/NTU: 5 % of measured value ±0.01 FNU/NTU

Ambient Temperature

0 to 50 °C TSS W sc

Calibration

Turbidity (TRB): Factory calibrated Solids (TS): To be calibrated by customer on site Zero point: Permanently calibrated in the factory

Diameter

40 mm

Flow Rate

3 m/s maximum

Length

Tank sensor: 330 mm

Max Temperature

60 °C

Measurement Method

Combined multiple beam alternating light method with infrared diode system and beam focusing
Turbidity (TRB): 2-channel 90º scattered light measurement in accordance with DIN/EN 27027/ISO 7027, wavelength = 860 nm
Solids (TS): 90º and 120º scattered light measurement, wavelength = 860 nm

Measurement Range 2

Solids (TS): 0.001 to 500 g/L With SiO₂ standard solution

Mounting Configurations

Immersion

Pressure Range

< 10 bar : TSS sc, TSS HT sc, TSS TITANIUM2 sc, TSS TITANIUM7 sc
< 16 bar : TSS VARI sc, TSS XL sc
< 6 bar : TSS W sc

Range

Turbidity (TRB): 0.001 to 9999 FNU

Reproducibility

Solids (TS): < Turbidity (TRB): <3%

Reproducibility Turbidity

< 3 %

Response Time

1 s < T90 < 300 s (adjustable)

Weight

Tank sensor, inline sensor (TriClamp): Approx. 3.53 lbs. (1.6 kg)

Weight 2

TSS VARI sc, TSS XL sc: Approx.1.5kg
