Accuracy

± 0.02 ppm or 3 % whichever is greater

Ambient Temperature

-5 to 100 °C (23 to 212 °F)

Calibration

Two points at cap replacement (zero and air), one during use (air)

Certifications

2004/108/EC - EN 61326-1

Display Resolution

0.1 ppb

Flow Rate

50 - 300 mL/min

Lower Limit of Detection (LOD)

0.015 ppm

Material

316 L Stainless Steel (1.4435), Silicone

Power supply

Universal 85-264 VAC @, 25 VA, 10-36 VDC, 25 W

Range

(Dissolved O₂)
0 to 40 (Dissolved O₂)

Repeatability

± 0.015 ppm or 2 % whichever is greater

Reproducibility

± 0.02 ppm or 3 % whichever is greater

Response Time

(90%)< (beer process)
< 10 (liquid phase)

Sample Pressure

1 to 20 bar absolute (14.5 to 290 psi)

Sample Temperature

Resistant to temperature from -5°C to 100°C (23 to 212°F)

Temperature Range

Accurate from -5 to 50 °C (23 to 122 °F)

Resistant to temperature from -5 to 100 °C (23 to 212 °F)

Temperature range

Accurate from Resistant to temperature from -5°C to 100°C (23 to 212°F)

Weight

M1100 12mm : 0.6 kg
M1100 28mm : 0.74 kg

Wetted Materials

316 L Stainless Steel (1.4435), Silicone
