Product Overview
Spesifikasi :
|
Accuracy |
0.1 m |
|
Cable Length |
10 m (optional extension cables available) |
|
Calibration Method |
One-off on commissioning, automatic |
|
Diameter Sensor |
185 mm |
|
Enclosure Rating |
IP68 |
|
Flow |
Max. 3 m/s (the presence of air bubbles affects the measurement) |
|
Length |
130 mm |
|
Maintenance Interval |
< 1 h/month typical |
|
Material |
POM: Wiper Magnet Encapsulating Compound: Epoxy resin; Wiper Rubber: Silicone rubber |
|
Measuring Principle |
Ultrasonic measurement |
|
Measuring range |
0.2 |
|
Mounting Configurations |
Sensor only |
|
Operating Temperature Range |
0 to 50 °C |
|
Pressure Range |
≤ 0.3 bar |
|
Range |
0.2 to 12 m sludge level |
|
Resolution |
0.03 m sludge level |
|
Response Time (adjustable) |
10 to 600 s |
|
Temperature Compensation |
automatic |
|
Warranty |
2 years |
|
Weight Sensor |
3.5 kg |
